扭力/功率/转数 | 简 易 型 号 | 额定电压V | 基座号mm | 额定电流A | 适配伺服驱动器 | 备注 |
2.4N.m/750W/3000rpm | RSDA080751 | 220V | 80 | 3 | 编码器： | |
3.5N.m/1KW/3000rpm | RSDA080102 | 220V | 80 | 4 | ||
4N.m/1.2KW/3000rpm | RSDA110122 | 220V | 110 | 5.9 | ||
5N.m/1.0KW/2000rpm | RSDA110102 | 220V | 110 | 5 | ||
6N.m/1.2KW/2000rpm | RSDA110182 | 220V | 110 | 6.6 | ||
4.77N.m/1KW/2000rpm | RSDA130102 | 220V | 130 | 4.72 | ||
9.55N.m/1KW/1000rpm | RSDA130102 | 220V | 130 | 4.72 | ||
7.16N.m/1.5KW/2000rpm | RSDA130152 | 220V | 130 | 6.87 | ||
4.78N.m/1.5KW/1500rpm | RSDA130152 | 220V | 130 | 6.41 | ||
9.55N.m/2KW/2000rpm | RSDA130202 | 220V | 130 | 9.18 | ||
6,.5N.m/2KW/3000rpm | RSDA130202 | 220V | 130 | 9.5 | ||
14.32N.m/3KW/2000rpm | RSDA130302 | 220V | 130 | 12.95 | ||
9.55N.m/3KW/3000rpm | RSDA130302 | 220V | 130 | 12.95 | ||
5.39N.m/0.85KW/1500rpm | RSDA130851 | 220V | 130 | 6.9 | ||
8.34N.m/1.3KW/1500rpm | RSDA130132 | 220V | 130 | 10.7 | ||
扭力/功率/转数 | 简 易 型 号 | |||||
4.77N.m/1KW/2000rpm | RSDA130102 | 380V | 130 | 2.5 | ||
9.55N.m/1KW/1000rpm | RSDA130102 | 380V | 130 | 3.3 | ||
7.16N.m/1.5KW/2000rpm | RSDA130152 | 380V | 130 | 4.1 | ||
4.78N.m/1.5KW/1500rpm | RSDA130152 | 380V | 130 | 4.2 | ||
9.55N.m/2KW/2000rpm | RSDA130202 | 380V | 130 | 6.5 | ||
6.5N.m/2KW/3000rpm | RSDA130202 | 380V | 130 | 5.8 | ||
14.32N.m/3KW/2000rpm | RSDA130302 | 380V | 130 | 9.6 | ||
9.55N.m/3KW/3000rpm | RSDA130302 | 380V | 130 | 8.3 | ||
5.39N.m/0.85KW/1500rpm | RSDA130851 | 380V | 130 | 3.5 | ||
8.34N.m/1.3KW/1500rpm | RSDA130132 | 380V | 130 | 5.4 | ||
11.5N.m/1.8KW/1500rpm | RSDA130182 | 380V | 130 | 8.4 | ||
14.32N.m/2.3KW/1500rpm | RSDA130232 | 380V | 130 | 10.1 | ||
18.6N.m/2.9KW/1500rpm | RSDA180292 | 380V | 180 | 11.9 | ||
28.4N.m/4.4KW/1500rpm | RSDA180442 | 380V | 180 | 16.5 | ||
35N.m/5.5KW/1500rpm | RSDA180552 | 380V | 180 | 20.8 | ||
48N.m/7.5KW/1500rpm | RSDA180752 | 380V | 180 | 25.7 |
